Window Installation Masonry / Concrete
Facade anchors
Window Production Plastics
EJOT facade anchor SDP-KB-10G/M8
®
with M8 threaded connection
Window Production Timber [mm] Ø Anchor length L Thickness of the non-load PU Order description Article number
carrying render layer t
[mm]
tol
[mm]
Anchor with A4 stainless steel screws (-E)*
10 80 0-10 100 SDP-KB-10Gx80/M8x13-E 8 532 080 813
10 100 10-30 100 SDP-KB-10Gx100/M8x13-E 8 532 100 813
AF13 *Anchor with steel screws with zinc-plated Cr(VI)-free coating (-V) upon request.
Window Production Aluminium Accessories
Order description PU Article number
Socket AF13-1/4“x50
1 9 250 719 001
Window Installation Coupling / False Edge Approval Application range Characteristic values AF 13
Drive
ETA-12/0502
Suitable for installation of support profiles
l
13 mm
with steel rods in rainscreen
Drill hole depth ≥ t
l Embedment of suspended ceilings Length M8 threaded connection +90 mm
l Fastening of ring bolts Embedment depth ≥ h v 70 mm
Window Installation Window Installation Masonry / Concrete Masonry / Concrete Properties Characteristic values 2 0.75 kN
Compressive strength aerated concrete [N/mm ]
Facade anchor with two-stage screw
l
Aerated concrete 2
Reliable form-fit in the substrate due to
l
combined expansion zones
Aerated concrete 4
1.87 kN
l High load-carrying capacity Aerated concrete 3 1.31 kN
Aerated concrete 6 MAAC 3.00 kN
2.00 kN
Partial safety factor γ
Window Installation Timber For planning and processing please note Characteristic bending moment 20.6 Nm / γ 1.87
Note
Stainless steel screw
approval ETA-12/0502.
Ms
Window Installation Attachments
Special Screws
Accessories / Tools
