Window Installation Masonry / Concrete
Facade anchors
Window Production Plastics

EJOT facade anchor SDF-KB-10V
®
with hexagon head

Fixing Fixing
Anchor
Ø thickness t fix thickness t
fix
[mm] length L (concrete) (masonry) PU Order description Product code Window Production Timber
[mm]
≤ [mm] ≤ [mm]
Anchors with steel screw with zinc-plated Cr(VI)-free coating (-V)
10 50 10 – 100 SDF-KB-10Vx50-V 8 581 050 450
10 60 20 10 100 SDF-KB-10Vx60-V 8 581 060 450 AF13/
T40
10 70 30 20 100 SDF-KB-10Vx70-V 8 581 070 450
10 80 40 30 100 SDF-KB-10Vx80-V 8 581 080 450 Window Production Aluminium
10 100 60 50 100 SDF-KB-10Vx100-V 8 581 100 450
10 120 80 70 100 SDF-KB-10Vx120-V 8 581 120 450
10 140 100 90 100 SDF-KB-10Vx140-V 8 581 140 450
10 160 120 110 100 SDF-KB-10Vx160-V 8 581 160 450
10 180 140 130 100 SDF-KB-10Vx180-V 8 581 180 450
10 200 160 150 100 SDF-KB-10Vx200-V 8 581 200 450
10 220 180 170 100 SDF-KB-10Vx220-V 8 581 220 450 Window Installation Coupling / False Edge
Anchor with A4 stainless steel screw (-E)
10 50 10 – 100 SDF-KB-10Vx50-E 8 581 050 650
10 60 20 10 100 SDF-KB-10Vx60-E 8 581 060 650 h
10 70 30 20 100 SDF-KB-10Vx70-E 8 581 070 650 h 1 t fix
h nom t tol
Approval
Application area Characteristic values ETA-10/0305
l Installation of metal components Hole depth in concrete h 1.1 ≥ 50 mm Window Installation Window Installation Masonry / Concrete Masonry / Concrete
l For all non-load carrying redundant systems Effective Embedment depth in concrete ≥ 40 mm
according to ETAG 020 h nom,1
l Suitable for the structural fastening of wall Hole depth in masonry h 1.2 ≥ 60 mm
cupboards, cladding, metal angle pieces Effective Embedment depth in masonry ≥ 50 mm
h
nom,2
Properties Drill hole diameter d 0 10 mm
l Anchor with an embedment depth of 40 mm Hole diameter of component to be fixed d f ≤ 10.5 mm h h 1,1 t fix Window Installation Timber h h h 1,2 t fix
in concrete Drive AF13/T40 h nom,1 tol t h nom,2 h 1 h nom tol t t tol t fix
l Two installation depths (embedment in ma-
sonry 50 mm) Characteristic loads
l Very short expansion part, for short installa- Tensile load N in concrete C12/15
Rk,p
tion times Temperature range 30 °C / 50 °C 4.50 kN
l Optimal expanding part due to radial expan- Temperature range 50 °C / 80 °C 4.00 kN
sion F brick Mz 20-1.8, NF 2.50 kN Window Installation Attachments
Rk
l Very high bending moment F solid lime sand brick KS 36, NF 4.00 kN Concrete
Rk
l Cr VI-free coating of the screw F solid lime sand brick KS 20, 8 DF 4.50 kN
Rk
l Product identification through different Transverse load V in concrete C12/15 h h
Rk,s
sleeve colours at h nom,1 = 40 mm h 1,1 t fix h 1,2 t fix
tol t
l Double safety lock against torsion for secure Anchor with steel screw h nom,1 7.93 kN h nom,2 tol t
installation Anchor with stainless steel screw A4 9.12 kN
Transverse load V at h nom,2 = 50 mm Special Screws
Rk,s
Note Anchor with steel screw 11.09 kN
Please note the European Technical Approval Anchor with stainless steel screw A4 12.94 kN
ETA-10/0305 in your planning and in the Bending moment M at h nom,1 =40 mm
Rk,s
processing of the products. Further information Anchor with steel screw 13.80 kN
about parameters and loads can be found in Anchor with stainless steel screw A4 16.09 kN Masonry
the approval. Side load M at h nom,2 = 50 mm
Rk,s
Anchor with steel screw 23.01 Nm Accessories / Tools
Anchor with stainless steel screw A4 26.62 Nm

53
