Window Installation Masonry / Concrete
Facade anchors
Window Production Plastics

EJOT facade anchor SDF-KB-10H
®
with hexagon head

Fixing
Ø Anchor length L
[mm] [mm] thickness t fix PU Order description Article number
≤ [mm] Window Production Timber
Anchors with steel screw with zinc-plated Cr(VI)-free coating (-V)
10 80 10 100 SDF-KB-10Hx80-V 8 513 080 420
10 100 30 100 SDF-KB-10Hx100-V 8 513 100 420
10 120 50 100 SDF-KB-10Hx120-V 8 513 120 420
10 140 70 100 SDF-KB-10Hx140-V 8 513 140 420 AF13/
T40
10 160 90 100 SDF-KB-10Hx160-V 8 513 160 420
10 180 110 100 SDF-KB-10Hx180-V 8 513 180 420 Window Production Aluminium
10 200 130 100 SDF-KB-10Hx200-V 8 513 200 420
10 220 150 100 SDF-KB-10Hx220-V 8 513 220 420
Anchor with A4 stainless steel screw (-E)
10 80 10 100 SDF-KB-10Hx80-E 8 513 080 620
10 100 30 100 SDF-KB-10Hx100-E 8 513 100 620
10 120 50 100 SDF-KB-10Hx120-E 8 513 120 620
10 140 70 100 SDF-KB-10Hx140-E 8 513 140 620 Window Installation Coupling / False Edge
10 160 90 100 SDF-KB-10Hx160-E 8 513 160 620
10 180 110 100 SDF-KB-10Hx180-E 8 513 180 620
10 200 130 100 SDF-KB-10Hx200-E 8 513 200 620
10 220 150 100 SDF-KB-10Hx220-E 8 513 220 620
h
h 1 h Approvalt fix
Application area Characteristic values nom ETA-10/0305
t tol
l Installation of metal components Hole depth in concrete h 1.1 ≥ 80 mm Window Installation Window Installation Masonry / Concrete Masonry / Concrete
l For all non-load carrying redundant systems Effective embedment depth h nom ≥ 70 mm
according to ETAG 020 Drill hole diameter d 0 10 mm
l Suitable for the structural fastening of wall Hole diameter of component to be fixed d f ≤ 10.5 mm
cupboards, cladding, metal angle pieces Drive AF13/T40
l For installation in rain screen
Characteristic loads
h
Properties Tensile load N in concrete C12/15 h h 1,2 t fix Window Installation Timber
h
Rk,p
t fix
1,1
tol t
4.50 kN tol t
h nom,1
l Approved for all common building materials Temperature range 30 °C / 50 °C h nom,2
l Reliable hold in problematic building material Temperature range 50 °C / 80 °C 4.00 kN
due to optimised expansion part Brick Mz 20-1.8, NF 4.00 kN
l Secure hold due to radial expansion Solid lime sand brick KS 36, NF 4.50 kN
l Cr VI-free coating of the screw Solid lime sand brick KS 20, 8 DF 4.50 kN
l Product identification through different Solid lightweight concrete brick V6, 2 DF 2.00 kN
sleeve colours Vertically perforated brick HLz 12-0.9, NF 2.00 kN Installation Window Installation Attachments
l Double safety lock against torsion for secure Perforated lime sand brick KSL 12, 4 DF 2.50 kN substrate
installation Cavity block made of lightweight concrete 1.20 kN
Hbl 10, 12 DF
Note Transverse load V Rk,s
Please note the European Technical Approval Anchor with steel screw 9.35 kN
ETA-10/0305 in your planning and in the Anchor with stainless steel screw A4 10.91 kN
processing of the products. Further information Bending moment M Rk,s Special Screws
about parameters and loads can be found in Anchor with steel screw 17.67 Nm
the approval. Anchor with stainless steel screw A4 20.62 Nm

Accessories / Tools

55
