Window Installation Attachments
Self-tapping screws
Window Production Plastics

EJOT self-tapping screw JA3-S-6.5
®

Ø Length
[mm] [mm] PU Order description Article number
6.5 35 500 JA3-S-6.5x35 3 029 800 311 Window Production Timber
6.5 95 250 JA3-S-6.5x95 3 029 300 311 T30

Application area Technical Data J3
l For fixing metal sections Head geometry Countersunk head
to timber, aluminium substructures ≤ 3 mm Drive T30
or steel substructures ≤ 2 mm
l For fixing treads, platform and balcony Window Production Aluminium
slabs to timber or aluminium substructures

Properties
l A2 stainless steel
Approval
Z-50.4-337 Window Installation Coupling / False Edge

Cross reference page
Bit TORX ....................................72
®
Hammer drill SDS plus ...............73
®
Window Installation Masonry / Concrete

EJOT self-tapping screw JZ3-S-6.3
®
Ø Length
[mm] [mm] PU Order description Article number Window Installation Timber
6.3 19 1,000 JZ3-S-6.3x19 3 029 400 311
6.3 25 500 JZ3-S-6.3x25 3 029 500 311 T30
6.3 35 500 JZ3-S-6.3x35 3 121 700 301
6.3 64 250 JZ3-S-6.3x64 3 029 600 311 J3
6.3 90 200 JZ3-S-6.3x90 3 029 700 311

Application area Technical Data Window Installation Window Installation Attachments Attachments
l For fixing metal sections, timber, treads, Head geometry Countersunk head
platforms and balcony slabs to steel or Drive T30
aluminium substructures

Special Screws
Properties Approval
Z-50.4-337
l A2 stainless steel
Cross reference page
Bit TORX ....................................72
®
Hammer drill SDS plus ...............73
®
Accessories / Tools

63
