Window Production Plastic
Self-drilling screws for fastening armouring
Window Production Window Production Plastics Plastics EJOT self-drilling screw type FD1

®

Ø Length PU Order description Article number
Window Production Timber PH 2 EJOSEAL 13 1,000 Self-drilling screw FD1 3.9x13 7 260 521 607
[mm]
[mm]
3.9
Zinc plated, blue passivated
3.9 9.5 1,000 Self-drilling screw FD1 3.9x9.5 7 260 520 601
3.9 13 1,000 Self-drilling screw FD1 3.9x13 7 260 521 601
1,000 Self-drilling screw FD1 3.9x16
7 260 522 601
3.9
16
Window Production Aluminium Bit cross-recess ...........................72 3.9 19 1,000 Self-drilling screw FD1 3.9x19 7 260 523 621
Cross reference
page
Hammer drill SDS plus ...............73
®
3.9
7 260 525 621
1,000 Self-drilling screw FD1 3.9x25
25
1,000 Self-drilling screw FD1 3.9x32
7 260 526 601
3.9
32
Order information: head finish in RAL colours on request
T15 recess upon request
Window Installation Coupling / False Edge Application range Technical Data Cross recess PH 2
7.5 mm
Head diameter
For fixing reinforced steel up to 3.0 mm in
l
Drive
PVC windows with tight fitting reinforcement
Thread type
ST thread
Properties
l Roller sorted quality for automated fastening
l Case-hardened steel
Window Installation Masonry / Concrete Processing information

Fasten with a rotation speed of
l
approximately 1,500 to 2,000 rpm

Window Installation Timber

Window Installation Attachments

Special Screws

Accessories / Tools

24
