Window Production Plastic
Self-drilling screws for fastening armouring
Window Production Window Production Plastics Plastics

EJOT self-drilling screw FD2R
®
with under-head ribs

Ø Length
[mm] [mm] PU Order description Article number Window Production Timber
EJOSEAL PH 2
3.9 16 1,000 Self-drilling screw FD2R 3.9x16 7 282 603 607 RC2
3.9 19 1,000 Self-drilling screw FD2R 3.9x19 7 282 605 607
3.9 25 1,000 Self-drilling screw FD2R 3.9x25 7 282 604 607
3.9 32 1,000 Self-drilling screw FD2R 3.9x32 7 282 606 607 Inspection document
Zinc plated, blue passivated No. 2614091-02 EPH Dresden
3.9 13 1,000 Self-drilling screw FD2R 3.9x13 7 282 616 601 Window Production Aluminium
3.9 16 1,000 Self-drilling screw FD2R 3.9x16 7 282 603 601 Cross reference page
Order information: head finish in RAL colours on request Bit cross-recess ...........................72
®
T15 recess upon request Hammer drill SDS plus ...............73

Application range Technical Data
l For fixing reinforced steel up to 3.0 mm in Head diameter 7.5 mm
PVC windows with tight fitting reinforcement Drive Cross recess PH 2 Window Installation Coupling / False Edge
l Mounting of fittings Thread type ST thread
Properties
l Burglary-resistant (RC2)
l Roller sorted quality for automated fastening
l Under-head ribs for easy countersinking of
the screw head in PVC Window Installation Masonry / Concrete
l Case-hardened steel

Processing information
l Fasten with a rotation speed of
Window Installation Timber
approximately 1,500 to 2,000 rpm

Window Installation Attachments

Special Screws

Accessories / Tools

21
