Window Production Plastic
Self-drilling screws for fastening armouring
Window Production Window Production Plastics Plastics

EJOT self-drilling screw FD42
®

Ø Length
[mm] [mm] PU Order description Article number
EJOSEAL Window Production Timber
3.9 16 1,000 Self-drilling screw FD42 3.9x16 7 260 822 607 PH 2
3.9 19 1,000 Self-drilling screw FD42 3.9x19 7 260 823 607
3.9 22 1,000 Self-drilling screw FD42 3.9x22 7 260 824 607
3.9 25 1,000 Self-drilling screw FD42 3.9x25 7 260 825 607
3.9 30 1,000 Self-drilling screw FD42 3.9x30 7 282 823 607 Cross reference page
3.9 32 1,000 Self-drilling screw FD42 3.9x32 7 260 826 607 Bit cross-recess ...........................72
®
3.9 38 1,000 Self-drilling screw FD42 3.9x38 7 260 827 607 Hammer drill SDS plus ...............73 Window Production Aluminium
3.9 45 1,000 Self-drilling screw FD42 3.9x45 7 260 828 607
Order information: T15 recess upon request.

Application range Technical Data
l For fixing metal core and fittings to thick- Head diameter 7.5 mm
walled and multi-ply PVC profiles and steel Drive Cross recess PH 2
or aluminium reinforcements up to 4 mm Thread type Special thread Window Installation Coupling / False Edge
thick.

Properties
l Drilling capacity up to 4.0 mm
l One type of screw for up to three applica-
tions
l Reduction of application errors Window Installation Masonry / Concrete
l Reliable fastening process
l Roller sorted quality for automated fastening
l Case-hardened steel

Window Installation Timber
Processing information
l Fasten with a rotation speed of 1,500 to
2,000 rpm

Window Installation Attachments
Application examples of the FD 42
Until now three different screw types were
needed for this application.

Special Screws

Accessories / Tools
