Window Production Plastic
Fitting screws
Window Production Window Production Plastics Plastics

EJOT window screw type DSK
®

Ø Length
[mm] [mm] PU Order description Article number
EJOSEAL Window Production Timber
4.2 25 1,000 Window screw DSK 4.2 x 25 2 228 425 607 PH 2
4.2 30 1,000 Window screw DSK 4.2 x 30 2 228 430 607
4.2 35 1,000 Window screw DSK 4.2 x 35 2 228 435 607
4.2 40 1,000 Window screw DSK 4.2 x 40 2 228 440 607
4.2 45 1,000 Window screw DSK 4.2 x 45 2 228 445 607 Cross reference page
Order information: head finish in RAL colours on request Bit cross-recess ...........................72
Hammer drill SDS plus ...............73 Window Production Aluminium
®
Application range Technical Data
l Manual assembly of tilt and turn fittings with Head diameter 7.3 mm
low rotation speed Drive Cross recess PH 2
l Fixing locking plates, strips and bearings in Thread type double-start thread
steel reinforcement with pre-drilling
Sheet thickness Pre-drill Ø
Properties 1.5 mm 3.0 mm Window Installation Coupling / False Edge
l With double cutting edge and symmetrically 2.0 mm 3.2 mm
arranged cutting surfaces 2.5 mm 3.5 mm
l Excellent alignment for precise and no run-
out fastening in PVC
l Roller sorted quality for automated fastening
l Case-hardened steel Window Installation Masonry / Concrete

Processing information
l Manual installation with rotation speed of
800 to 1500 rpm (see chart)

Window Installation Timber

Window Installation Attachments

Special Screws

Accessories / Tools

17
