Pos. Art.No. Qty Description Type

J 22302 2 KW 1600/S Commissioning trolley KW 1600/S
Length 1600 mm, width 1150 mm, complete with remova-
ble steering rollers dia. 125 mm, optional with felt or rubbe-
rized cover, to be stored into one another. Capacity 750 kg.

K 22300 2 GF 13/24 Compartment trolley GF 13/24
Length 1300 mm, width 1100 mm, 24 panes can be accom-
modated. Capacity 750 kg.

L 34234 1 TRIM 300 NR Universal mitre saw TRIM 300 NR
Universal oscillating and mitre saw, complete with carbide
tipped saw blade, diameter 300mm, aluminium table plate
with longitudinal stop, manual clamps, mitre 45° RS and 45°
LS possible, sawing head inclinable up to 45°.

M 22290 1 HS 10.1 Gasket trolley HS 10.1
Length 600 mm, width 600 mm, height 900 mm, 4 castor
wheels, 2 of them with locking brakes. Two winches can be
accommodated.

N 36058 1 RSDK 5,5-250 Stationary screw-type compressor RSDK 5,5-250
for 30 units 650 l effective, pressure: 10 bars, belt diven,
5.5 kW, 400 V, great sound insulation, 570x1415x1435mm
(width x depth x height) incl. delta switch (mandatory from
N: RQ LQFO DLU GU\HU LQFO FRQQHFWLQJ SLSLQJ LQFO DLU ¿OWHU
mat incl. control of sense of rotation all ready for use moun-
ted on a 250 l tank Advantages: oil cooling = also suitable
IRU FRQWLQXRXV RSHUDWLRQ LQVWDOOHG ¿OWHU FRQVWDQW DLU TXDOLW\
big aftercooling = arid air sound insulation as a standard
good accessibility = simple and quick maintenance incl.
dryer = protects tools and machines against wear caused
by condensation = cost saving compact system = set up,
connect - ready.

O 22826 1 AP 30 Connection package AP 30

Software package Upon request

6XEMHFW WR PRGL¿FDWLRQV DQG HUURUV
