Pos. Art.No. Qty Description Type

1 26439 1 DGU 500 Double mitre saw DGU 500
cutting length max. 3560mm, min. 560mm (260mm); positi-
oning according to digital measuring display; complete with
2 saw blades (diameter 500mm); with intermediate support
IRU ORQJ SUR¿OHV YHUWLFDO DQG KRUL]RQWDO FODPSV

Alternativ
37072 1 DGL 200-M/37 Double mitre saw DGL 200-M/37
0DQXDO OHQJWK DGMXVWPHQW OHIW KDQG VDZ ¿[HG ULJKW KDQG
saw can be moved. Suitable for saw blades of a diam. of
500 mm. 2 threephase motors of 2,2 kW each, 2800 rpm.
Pneumatic feed of saw blade and two horizontal clamping
cylinders. Angle gauge from 45° to 90°. Connection of ex-
WUDFWLRQ PP IRU HDFK VDZ 3UHVVXUH UHJXODWRU ZLWK ¿OWHU
lockable main switch. Incl. container for waste and cuttings,
cleaning pistol and maintenance unit with automatic draina-
ge Cutting length 3700 mm max., 300 min. inner dimension.
:LWK FHQWUDO SUR¿OH VXSSRUW PDQXDOO\ DGMXVWDEOH
RXWVLGH SUR¿OH VXSSRUW VDZ EODGHV +0 [
x 4 (321216), socket (37153)

2 34040 1 TRS 275 K Metal cutting saw - complete package TRS 275
Saw blade dia. 275 mm, complete with machine base, sa-
wblade, 2 adapters with roller conveyor RO-3 (no. 26378),
length stop RO/L-3 (no. 26382+26386) and coolant concen-
trate 10 l (no. 34100), LH or RH mounting possible *PLEA-
SE INDICATE THROUGHPUT DIRECTION.

3 22651 1 UG 5000 Machine main base UG 5000
For dowel hole drill unit and screwdriver

3.1 25628 1 DS 1700 Screw advance unit DS 1700
with integrated screw feed standard adjustment to drill
screws: 3,9 x 7 x 19mm . other screw dimensions can be
adjusted for the customer in the following dimensions: shaft
diameter 3.5 - 4.8 mm, head diameter 7-9 mm, length 12-
40 mm (please send samples) compressed air connection
R 3/8“, 7 bar, air consumption 600 l / min, air consumpti-
on / cycle 50 l, appliance connection R 1/4“, feed capacity
30 - 60 screws / min, screwing capacity 6 - 15 Nm, 400 W
idle speed 2000 rpm, , dimensions: 1130 x 320 x 660mm
(h/w/d), with material support and safety guard to avoid in-
YROXWDU\ DFFHVV WR WKH ZRUNLQJ DUHD PD[ SUR¿OH FODPSLQJ
ZLGWK PP PD[ SUR¿OH KHLJKW PP GHSHQGV RQ
jaw length.

3.2 26376 2 RO-1 Roller conveyor RO-1
length 1000mm, roller width 300mm, height of roller con-
veyor 850mm - 1050mm, roller diameter 50mm with 200mm
distance, load capacity per roller around 15kg including
connecting angle and one support

6XEMHFW WR PRGL¿FDWLRQV DQG HUURUV
