P. 12
Pos. Art.No. Qty Description Type
9 22062 1 HS 0576 Weld seam cleaning unit universal HS 0576
For angles of 0-180°. Single-side operation
(1 cleaning knife).
Cutting length 380 mm.
10 22239 1 STH 2500 Pivot table STH 2500
Height adjustable, with retractable rollers, lateral extensi-
RQ WR PP ÀDW FODPSLQJ F\OLQGHUV ZLWK KDQG YDOYH
Working area equipped with sliding ledges, pneumatic tilting
and height adjustable when in vertical position. Carrying ca-
pacity 150 kg.
11 22259 1 BW 2000 Hardware trolley BW 2000
Length 1100 mm, depth 700 mm, height 1100 mm, 4 castor
wheels, 2 of them with locking brakes. 7 compartments, 2
wooden trays.
11.1 22602 1 BS 2000/BW Gear cropper BS 2000/BW
For BW 2000, incl. length stop system, maintenance unit.
12 25617 1 KV 2800 HF Checking and glazing unit KV 2800 HF
without height adjustment, clamping width 2740mm clam-
ping height 2200 mm, length 3650 mm, width 800 mm,
height 2500 mm, carrying capacity 300 kg weight 440 kg.
13 26259 1 GLS 200 Glazing bead saw, automatic GLS 200
for mitre cuts of 45°, automatic pneumatic feed of saw bla-
de via start key, 4 pneumatic clamping cylinders (rubberi-
zed), operated via foot valve, incl. glass simulation unit with
16-fold turret stop, electric control, 2 three-phase motors
0.75 kW each, completely ready for operation, working cy-
cle from back to front 2 x HM saw blade 200x2,0x32mm 1
x HSS saw blade 103x2.0x32mm rh, 1 x HSS saw blade
103x2.0x32mm lh, *WITHOUT pieces which depend on the
SUR¿OHV
13.1 26338 1 */6 =8 6HW RI SUR¿OH GHSHQGHQW OLPLWHUV GLS-ZU
FRQVLVWLQJ RI FRXQWHU SUR¿OH VXSSRUWV [ OK [ UK IRU WZR
glazing beads) suitable for GLS 102 and GLS 200.
13.2 26337 1 MMS-GLS Manual measuring system MMS-GLS
complete for measuring up to 4 different lenghts up to 3
P LQFO P DQG P PHDVXULQJ URG ZLWK PHDVXULQJ ¿Q-
gers each, incl. support for the measuring rods, suitable for
GLS-A, GLS 102 and GLS 200.
13.3 26283 1 */6 3$ 3UR¿OH VXSSRUW P GLS-PA6
complete with supports for GLS.
6XEMHFW WR PRGL¿FDWLRQV DQG HUURUV
