Pos. Art.No. Qty Description Type Pos. Art.No. Qty Description Type

1 26439 1 DGU 500 Double mitre saw DGU 500 7 34203 1 GLZ Glazing bead saw GLZ
cutting length max. 3560mm, min. 560mm (260mm); positi- Hand held for cutting to dimension of glazing beads of
oning according to digital measuring display; complete with wood, aluminium or vinyl. 45° or 90°, with 230 V motor, SHC
2 saw blades (diameter 500mm); with intermediate support (sintered hard carbide) sawblade (34235), frame clamps.
IRU ORQJ SUR¿OHV YHUWLFDO DQG KRUL]RQWDO FODPSV

7.1 34204 1 Aluminium limiters for GLZ PDQXIDFWXUHG DFFRUGLQJ WR SUR¿OH GLZ-Z
2 34130 1 NEW 250 Iron saw NEW 250
for all-day use, incl. sawblade dia. 250 mm, RPM 40 1/min,
1.3 kW, 400 V, with short stop, machine base, saw blade Alternativ
and double clamping arm for low-burr cuts. (suitable for
small companies)
7 26258 1 GLS 102 Glazing bead saw GLS 102
manual for mitre cuts of 45°, manual feed, 4 pneumatic
clamping cylinders (rubberized), operated via foot valve,
simple electric control, 2 three-phase motors 0.75 kW each,
3 26726 1 WS 203 Water drainage router WS 203 completely ready for operation, working cycle from back to
For the milling of water slots and ventilation slots at vinyl front, 2 x HSS saw blade 200x2.0x32mm, 1 x HSS saw bla-
ZLQGRZ SUR¿OHV SRZHUIXO FXWWLQJ PRWRUV ZLWK VRIW VWDUW de 103x2.0x32mm rh 1 x HSS saw blade 103x2.0x32mm lh
function for burr-free milling (speed can be adjusted). :,7+287 SLHFHV ZKLFK GHSHQG RQ WKH SUR¿OHV
- Automatic milling operation
- Optional switch-in of motors for drainage towards the
front, bottom or top 7.1 26338 1 */6 =8 6HW RI SUR¿OH GHSHQGHQW OLPLWHUV GLS-ZU
- Quick adjustment with clamping levers and turret stops FRQVLVWLQJ RI FRXQWHU SUR¿OH VXSSRUWV [ OK [ UK IRU WZR
- Solid heavy load guides and hardened and ground shafts glazing beads) suitable for GLS102 and GLS200
with recirculating ball bushings
- Pneumatic clamping unit horizontal
3QHXPDWLF SUR¿OH VWRS [ ULJKWVLGH [ OHIWVLGH 8 K005929 1 Hand drilling machine
- Large support table (powder-coated) Speed of milling
motor 1/min: 11.000 - 33.000 Max. milling path: 0-40 mm
Electrical connection: 230V - 50/60Hz (L1-N-PE) Total 9 22681 1 DS 1750 Screw advance unit DS 1750
max. power: 2,2 kW Air connection: 6 bar with funnel for manual screw feed, standard adjustment to
drill screw: 3.9 x 7 x 19 mm. . Other screw dimensions can
be adjusted for the customer in the following measures:
4 34198 1 A 23 A Copy router A 23 A Shaft diameter: 3.5 - 4.8 mm, head diameter: 7-9 mm, length
with milling motor 12000/min. and olive drill Ø=5 mm, (10- 12-40 mm, (samples required). Compressed air connection
12-10), universal copy-stencil, motor 900 1/min., with mill/ R 3/8“, 7 bar, air consumption 600 l / min, air consumption
drill tools, pneumatic clamp, with short sidestop and 4 fol- / cycle 50 l, appliance connection R 1/4“, feed capacity 30-
ding stop and manual advance. 60 screws / min, screwing capacity 6-15 Nm, 400 W. Idle
speed 2000 rpm, dimensions: 700 x 320 x 500 mm (h/w/d).
With material support and safety guard to avoid involutary
5 25467 1 AKS 1020 Single head welding machine AKS 1020 DFFHVV WR WKH ZRUNLQJ DUHD PD[ SUR¿OH FODPSLQJ ZLGWK
For angle weldings from 30°-180°. With strength optimisati- PP PD[ SUR¿OH KHLJKW PP GHSHQGV RQ MDZ OHQJWK
on, weld seam limitation to 2.0 mm on top and bottom side,
LQFO VWUDLJKW ¿[WXUHV +HDWLQJ HOHPHQW IURP DERYH :LWKRXW
RXWHU FRQWRXU EORFNV DQG VXSSRUW VWDQG 3UR¿OH KHLJKW PD[ 9a 22651 1 UG 5000 Machine main base UG 5000
130 mm. For dowel hole drill unit and screwdriver

5.1 311432 1 Set of stands with support rollers for AKS 1020/1150

6 25538 1 SV A-21 Corner cleaning machine SV-A 21
:LWK DXWRPDWLF HQG PLOOHU IRU 39& ZLQGRZ SUR¿OHV RU VL-
milar. With automatic turn-off of machine at power failure,
electro-pneumatic control, electronically controlled mo-
WRU EUDNH &RUQHU FOHDQLQJ PDFKLQH ZLWK DXWRPDWLF SUR¿OH
taking in, quick change bushing 32 mm diameter, coun-
ter-clockwise, cutting shaft accomodation for a set of cutters
(max. disk diameter 230 mm). Triple cutting depth stop,
adjustable cutting speed, grooving knife top and bottom.
Automatic end miller - sens of rotation clockwise/counter-
clockwise reversible, stepless 60°-90°-22.5°, pneumatic
clamping device, adustable cutting speed, aluminium sheet
protection. Stepless 60° - 90° - 22.5°.

6XEMHFW WR PRGL¿FDWLRQV DQG HUURUV 6XEMHFW WR PRGL¿FDWLRQV DQG HUURUV
