Pos. Art.No. Qty Description Type

1 26439 1 DGU 500 Double mitre saw DGU 500
cutting length max. 3560mm, min. 560mm (260mm); positi-
oning according to digital measuring display; complete with
2 saw blades (diameter 500mm); with intermediate support
IRU ORQJ SUR¿OHV YHUWLFDO DQG KRUL]RQWDO FODPSV

2 34130 1 NEW 250 Iron saw NEW 250
for all-day use, incl. sawblade dia. 250 mm, RPM 40 1/min,
1.3 kW, 400 V, with short stop, machine base, saw blade
and double clamping arm for low-burr cuts. (suitable for
small companies)

3 26726 1 WS 203 Water drainage router WS 203
For the milling of water slots and ventilation slots at vinyl
ZLQGRZ SUR¿OHV SRZHUIXO FXWWLQJ PRWRUV ZLWK VRIW VWDUW
function for burr-free milling (speed can be adjusted).
- Automatic milling operation
- Optional switch-in of motors for drainage towards the
front, bottom or top
- Quick adjustment with clamping levers and turret stops
- Solid heavy load guides and hardened and ground shafts
with recirculating ball bushings
- Pneumatic clamping unit horizontal
3QHXPDWLF SUR¿OH VWRS [ ULJKWVLGH [ OHIWVLGH
- Large support table (powder-coated) Speed of milling
motor 1/min: 11.000 - 33.000 Max. milling path: 0-40 mm
Electrical connection: 230V - 50/60Hz (L1-N-PE) Total
max. power: 2,2 kW Air connection: 6 bar

4 34198 1 A 23 A Copy router A 23 A
with milling motor 12000/min. and olive drill Ø=5 mm, (10-
12-10), universal copy-stencil, motor 900 1/min., with mill/
drill tools, pneumatic clamp, with short sidestop and 4 fol-
ding stop and manual advance.

5 25467 1 AKS 1020 Single head welding machine AKS 1020
For angle weldings from 30°-180°. With strength optimisati-
on, weld seam limitation to 2.0 mm on top and bottom side,
LQFO VWUDLJKW ¿[WXUHV +HDWLQJ HOHPHQW IURP DERYH :LWKRXW
RXWHU FRQWRXU EORFNV DQG VXSSRUW VWDQG 3UR¿OH KHLJKW PD[
130 mm.

5.1 311432 1 Set of stands with support rollers for AKS 1020/1150

6 25538 1 SV A-21 Corner cleaning machine SV-A 21
:LWK DXWRPDWLF HQG PLOOHU IRU 39& ZLQGRZ SUR¿OHV RU VL-
milar. With automatic turn-off of machine at power failure,
electro-pneumatic control, electronically controlled mo-
WRU EUDNH &RUQHU FOHDQLQJ PDFKLQH ZLWK DXWRPDWLF SUR¿OH
taking in, quick change bushing 32 mm diameter, coun-
ter-clockwise, cutting shaft accomodation for a set of cutters
(max. disk diameter 230 mm). Triple cutting depth stop,
adjustable cutting speed, grooving knife top and bottom.
Automatic end miller - sens of rotation clockwise/counter-
clockwise reversible, stepless 60°-90°-22.5°, pneumatic
clamping device, adustable cutting speed, aluminium sheet
protection. Stepless 60° - 90° - 22.5°.

6XEMHFW WR PRGL¿FDWLRQV DQG HUURUV
