Special Screws
Industrial applications
Window Production Plastics EJOT WD self-drilling wing screws

®

Thread Drilling Wood
Length Head Ø length DIN perfor- thickness PU Order description Article number
Window Production Timber Ø 4.2 mm 8.4 [mm] O-H 1.5 - 3.0 6 - 20 500 WD self-drilling screw ST 7 389 102 601
[mm]
[mm]
[mm]
mance
38
22
Ø 4.8 mm 4.2x38-O-H
WD self-drilling screw ST
38 9.5 23 T25 2.5 - 4.0 8 - 18 500 4.8x38-O-T25 ribs 7 289 196 601
Window Production Aluminium 50 9.5 35 T25 2.5 - 4.0 8 - 30 250 WD self-drilling screw ST 7 289 197 601
4.8x50-O-T25 ribs
WD self-drilling screw ST
70
55
9.5
2.5 - 4.0
250
8 - 50
7 289 198 601
T25
Ø 5.5 mm 4.8x70-O-T25 ribs
WD self-drilling screw ST 7 389 112 601
500
45
O-H
25
10.8
10 - 22
2.5 - 5.0
5.5x45-O-H
Window Installation Coupling / False Edge 50 10.8 30 T25 2.5 - 5.0 10 - 30 200 WD self-drilling screw ST 7 289 206 601
5.5x50-O-T25 ribs
WD self-drilling screw ST
T25
30
200
10 - 40
2.5 - 5.0
10.8
60
7 289 207 601
5.5x60-O-T25 ribs
WD self-drilling screw ST
80 10.8 60 T25 2.5 - 5.0 10 - 60 200 7 289 208 601
5.5x80-O-T25 ribs
WD self-drilling screw ST
Window Installation Masonry / Concrete 100 10.8 60 T25 2.5 - 5.0 10 - 100 200 5.5x100-O-T25 ribs 7 289 202 601
10 - 80
WD self-drilling screw ST
120
200
2.5 - 4.0
7 289 203 601
10.8
60
T25
5.5x120-O-T25 ribs
150 10.8 60 T25 2.5 - 5.0 10 - 130 200 WD self-drilling screw ST 7 289 204 601
5.5x150-O-T25 ribs
Ø 6.3 mm 15.0 30 T40 2.5 - 8.0 10 - 38 250 WD self-drilling screw UNC 7 389 161 601
Window Installation Timber Other designs on request 6.3x70-O-T40 ribs
70
Application range
l Special screw for fixing timber to metal
substructures
Window Installation Attachments Properties
The wings ream out the wood larger than
l
the thread diameter
screw and thus possible damage to the drill
l The wings prevent force feeding of the
point
Zinc-plated, blue passivated finish
l
Special Screws Special Screws l Case-hardened steel
Processing information
l To ensure shearing of the wings, the materi-
al thickness of the metal substructure must
be at least 1.5 mm
Accessories / Tools
