Window Production Aluminium
Flow drill screws
Window Production Plastics

EJOT stainless steel screw type FDS ®
®

Ø Length Ø Head
[mm] [mm] [mm] Head style Drive PU Order description Article number Window Production Timber
M4 20 8.2 Countersunk head PH 2 1,000 FDS M4x20 7 655 004 321 RC3
M4 20 9.2 Countersunk head PH 2 100 FDS M4x20-S 7 555 014 320
M5 20 9.2 Countersunk head PH 2 1,000 FDS M5x20 7 665 006 321
M5 20 9.3 Countersunk head T25 1,000 FDS M5x20 7 635 006 321 PH 2 PZ 2 T25
M5 20 11.0 Pan head w. PH 3 100 FDS M5x20-S 7 545 011 320
M5 25 9.2 Countersunk head PZ 2 1,000 FDS M5x25 7 698 003 320
M5 30 9.2 Countersunk head T25 100 FDS M5x30 7 638 007 320 Cross reference page Window Production Window Production Aluminium Aluminium
Order information: Further lengths and types on request Bit cross-recess ...........................72
Bit TORX ....................................72
®
Hammer drill SDS plus ...............73
®
Application range Technical data
l Fastening to thin-walled sheet metal Thread type metric
l High strength sheet metal joints e.g.
carriages of lift and slide doors closing parts Stages of the FDS installation
of burglar-proof windows Window Installation Coupling / False Edge

Properties
l The flow drilling forms a through draught in
the sheet metal, two or
three turns of thread are formed within
l The subsequent shrinkage of the cooling 1.) Warming 2.) Penetration 3.) Forming of
through draught causes high loosening up of the sheet of the material the cylindrical Window Installation Masonry / Concrete
torques and good vibration resistance metal through with the tapered through draught
l A high-strength joint is formed application pres- screw point
sure and high
l Made of A2 stainless steel rotation speed
l RC3 burglar resistance possible
Processing
The maximum possible through draught is Window Installation Timber
formed without pre-drilling and with fastening
equipment with high rotation speed and high
axial load. A through draught of approximately
double material thickness is formed when ins- 4.) Chipless for- 5.) Full thread 6.) Tightening of
Window Installation Attachments
talling with reduced pre-drill diameter. ming of a female engagement the screw with
machine thread pre-set torque

Special Screws

Accessories / Tools
