Window Production Aluminium
Self-tapping fitting screws made of stainless steel
Window Production Plastics

EJOT PT screw type DG 55-C
®
pan head with point / WN1542

Ø Length Clamp thickness
[mm] [mm] [mm] PU Order description Article number Window Production Timber
5.5 42 35 500 DG 55x42-C 2 590 228 320
Further lengths on request
On request also with sealing washer PH 2

Application range Technical data
l Clamped joint in a U-shaped profile Head diameter 11 mm
Thread type DG 55 Cross reference page Window Production Window Production Aluminium Aluminium
Properties Drive Cross recess PH 2 Bit cross-recess ...........................72
Hammer drill SDS plus ...............73
®
l A2 stainless steel
l For thread geometries optimised for alumi-
nium for high pull-out strength
