Window Production Plastic
Clip screws
Window Production Window Production Plastics Plastics

EJOT Rollo self-drilling screw type RD
®
Dimensions [mm]
Order description PU Profile Article number
D d Length
Rollo self-drilling screw 9.5 6.8 9.0 1,000 Salamander 2 289 121 602*
RD-1 4x9 yellow Window Production Timber
PH 2
Rollo self-drilling screw 10.5 7.4 13.0 1,000 Rehau, Inoutic, KBE, Aluplast, 2 289 122 602*
RD-2 4x13 red Deceuninck, Roplasto
Rollo self-drilling screw 12.0 8.4 12.0 1,000 Trocal, Stöckel 2 289 123 602*
RD-3 4x12 white
Rollo self-drilling screw 11.0 8.6 10.0 1,000 Kömmerling, Gealan, 2 289 124 602* Cross reference page
RD-4 4x10 blue Roplasto Bit cross-recess ...........................72
Hammer drill SDS plus ...............73
®
Rollo self-drilling screw 11.0 8.4 12.0 1,000 Hocoplast, Aluplast 2 289 125 602 Window Production Aluminium
RD-5 4x12 green
Rollo self-drilling screw 9.5 6.8 12.0 1,000 Veka 2 289 126 602
RD-6 4x12 yellow
Order information: Further lengths upon request.
*also available as full-steel version

Application range Technical Data Window Installation Coupling / False Edge
Clamping of Drive Cross recess PH 2
l roller-shutter profiles Thread type double-start thread
l drip sills

Window Installation Masonry / Concrete

Window Installation Timber

Window Installation Attachments

Special Screws

Accessories / Tools
